Bobcat MT 120 Mini Track Loader
$45,999.00
The Bobcat MT120 mini track loader leads its class in lift height and reach, delivering heavy-lifting performance and high value with low overall cost of ownership.
-
- 1,200-pound rated operating capacity
- Best-in-class lift height and reach at 88.2 inches
- Easy-to-operate pilot controls
- Low maintenance design with reduced daily upkeep
- Premium features at a highly competitive price
Description
Bobcat MT120 Mini Track Loader starts at $42,999
The Bobcat MT120 mini track loader leads its class in lift height and reach, delivering heavy-lifting performance and high value with low overall cost of ownership.
- 1,200-pound rated operating capacity
- Best-in-class lift height and reach at 88.2 inches
- Easy-to-operate pilot controls
- Low maintenance design with reduced daily upkeep
- Premium features at a highly competitive price
| Engine | |
|---|---|
| Engine Model | 3L123-BC4A |
| Engine Make | Daedong |
| Engine Cooling | Liquid |
| Emissions Tier (EPA) | Tier 4 |
| Engine Fuel | Diesel |
| Horsepower | 24.5 hp |
| Displacement | 75.2 cubic in |
| Number of Cylinders | 3 |
| Performance | |
| Rated Operating Capacity (ISO) | 1200 lbs |
| Ground Pressure (Standard Tracks) | 4.3 psi |
| Ground Pressure (Optional Tracks) | 3.9 psi |
| Carry Position ROC with Standard Counterweight | n/a |
| Tipping Load | 3469 lbs |
| Operating Weight | 3720 lbs |
| Travel Speed | 4.7 mph |
| Travel Speed – Reverse | 4.7 mph |
| Ground Pressure (Rubber) | n/a |
| Capacities | |
| Fuel Tank | 8.1 gal |
| Hydraulic System | |
| Pump Capacity | 12 gpm |
| System Relief @ Quick Couplers | 3045 psi |
| Auxiliary Std Flow | 11.8 gpm |
| Dimensions | |
| Length | 107.3 in |
| Length without Attachment | 86.8 in |
| Length with Standard Bucket | 107.3 in |
| Width | 35.6 in |
| Width (with bucket) | 3 ft |
| Height | 57.6 in |
| Height to Bucket Hinge Pin | 88.2 in |
| Dump Angle @ Maximum Height | 45 deg |
| Reach @ Maximum Height | 22.2 in |
| Ground Clearance | 7.9 in |
| Angle of Departure | 25 deg |
| Length of track on ground | 55.7 in |
| Track Width – Optional | 11 in |
| Track Width – Standard | 9.1 in |
| Controls | |
| Vehicle Steering | ISO Pattern, left hand joystick |
| Lift and Tilt | Controlled by right hand joystick |
| Auxiliary Hydraulics | Controlled by thumb switch on right hand joystick |
| Features | |
| Lift-Arm Support, Auxiliary Hydraulics, Spark Arrestor Muffler, Bob-Tach Attachment System, Common Industry Interface, Wide Track, Neutral Start Interlocks, Lift Arm Lockout With Manual Bypass, Tilt Lockout, Built-In Tie Down & Crane/Lift Locations | |
| Compatible Attachments | |
| Snow Blowers: 26X36, 26X48, 26X56 Landplane: 48″ Deluxe Landplane Trenchers: LT113 x2 Grapple, Brush: 36″, 42″ Pallet Forks: Mini Pallet Fork Frame, Pallet Fork Frame x2 Grapple, Root: 36″, 48″ Industrial Grapples: 36″, 48″ Buckets – General Purpose: 36″ GP, GPX, GPX CII; 44″ GP, GPX, GPX CII; 50″ GP, GP (463), GPX Buckets – Light Material: 44″, 54″ Dumping Hopper: Model 10 Forks – Utility: 36″, 5 Teeth Grapple, Utility: 32″ GP, 32″ Utility Buckets – Construction & Industrial: 36″ Mini Const./Ind. Snow Blades: 60″ Soil Conditioner: 48-in. Manual Vibratory Plow: VP12 Stump Grinder: SG 30 Adapter Plate: Adapter Plate Diggers: 12S Digger Boring Unit: Boring Unit Breakers: HB680 with Nail Point, MI NB140 Buckets – Dirt: 36″, 50″, NAGS 44″ Sweepers: 44″ Sweeper Bucket Tillers: 40″ Rotary Tiller Brushcat: 44″ (30cc) Buckets – SAL Utility: MI 44″ SAL UTILITY Angle Broom: 52″, 64″ Log Grapple: 56″ Augers: 12PH, 14PH Auger Drive Unit |
|
Additional information
| Weight | 1000 kg |
|---|
